Display Assembly
WARNING: Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION: To help prevent damage to the system board, remove the main battery
(see "Removing the Battery Pack" on page 13) before working inside the computer.
Removing the Display Assembly
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the battery pack (see "Removing the Battery Pack" on page 13).
3
Remove the compartment door (see "Removing the Compartment Door"
on page 15).
4
Remove the center control cover (see "Removing the Center Control
Cover" on page 49).
5
Remove the keyboard (see "Removing the Keyboard" on page 55).
6
Disconnect the antenna cables from the Mini-Card (see "Removing the
Mini-Card" on page 59).
7
Disconnect the wirelessHD card cable from the connector on the
wirelessHD card (see "Removing the WirelessHD Card" on page 63).
8
Loosen the two captive screws that secure the display cable to the system
board.
9
Using the pull-tab, pull the display cable to disconnect the display cable
from the connector on the system board.
