Graphics-Card Heat Sink Fan 31
7
Graphics-Card Heat Sink Fan
WARNING: Before working inside your computer, read the safety information that
shipped with your computer. For additional safety best practices information, see
the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
WARNING: The graphics-card assembly may be very hot during normal
operation. Ensure that it has had sufficient time to cool before you touch it.
CAUTION: Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION: To help prevent damage to the system board, remove the main battery
(see "Removing the Battery Pack" on page 13) before working inside the computer.
Removing the Graphics-Card Heat Sink Fan
1
Follow the instructions in "Before You Begin" on page 9.
2
Remove the battery pack (see "Removing the Battery Pack" on page 13).
3
Remove the compartment door (see "Removing the Compartment Door"
on page 15).
4
Disconnect the graphics-card heat sink fan cable from the connector on
the system board.
5
Loosen the three captive screws that secure the graphics-card heat sink fan
to the chassis.
6
Lift the graphics-card heat sink fan along with the cable away from the
chassis.
