98 System Board
9 Replace the wirelessHD card (see "Replacing the WirelessHD Card" on
page 64).
10 Replace the display assembly (see "Replacing the Display Assembly" on
page 73).
11 Replace the power button board (see "Replacing the Power Button Board"
on page 68).
12 Replace the Mini-Card (see "Replacing the Mini-Card" on page 61).
13 Replace the memory module(s) (see "Replacing the Memory Module(s)"
on page 27).
14 Replace the keyboard (see "Replacing the Keyboard" on page 57).
15 Replace the center control cover (see "Replacing the Center Control
Cover" on page 52).
16 Replace the processor module (see "Replacing the Processor Module" on
page 46).
17 Replace the processor heat-sink (see "Replacing the Processor Heat-Sink"
on page 42).
18 Replace the processor heat-sink fan (see "Replacing the Processor
Heat-Sink Fan" on page 38).
19 Replace the graphics-card assembly (see "Replacing the Graphics-Card
Assembly" on page 36).
20 Replace the graphics-card heat sink fan (see "Replacing the Graphics-Card
Heat Sink Fan" on page 32).
21 Replace the coin-cell battery (see "Replacing the Coin-Cell Battery" on
page 18).
22 Replace the hard drive(s) (see "Replacing the Hard Drive(s)" on page 22).
23 Replace the compartment door (see "Replacing the Compartment Door"
on page 16).
24 Replace the battery pack (see "Replacing the Battery Pack" on page 14).
25 Replace any cards or blank that you removed from the 9-in-1 Media Card
Reader.
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
