Installing display cable
Steps
1. Affix the adhesive tape to secure the display cable to the display back cover.
2. Route the display cable into the hinge cap and secure the rubber stopper [1],[2].
3. Connect the camera cable connector to the camera module [2].
4. Affix the adhesive tape to secure the camera cable connector [3].
64
Removing and Installing
