Dell Chromebook 3100 2-in-1 - Display Assembly; Removing Display Assembly

Next steps
1. Install the system board.
2. Install thebattery.
3. Install the base cover.
4. Install the microSD card.
5. Follow the procedure in after working inside your computer.
Display assembly
Removing display assembly
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the microSD card.
3. Remove the base cover.
4. Remove the battery.
Steps
1. Disconnect the EMR sensor cable [1].
2. Remove the single (M2.0x3.0) screw that secures the wireless bracket to the system board [2].
3. Lift the wireless bracket and disconnect the wireless antennas [3, 4].
