Dell Dimension XPS R Series User Manual

System Overview 1-11
)LJXUH  '& 3 RZHU &RQQHFWRUV 3 3 3 3 DQG 3
)LJXUH  '& 3 RZHU &RQQHFWRU 3
1 2 3 4
+5 VDC (red)
common (black)
common (black)
+12 VDC (yellow)
P2,
P3,
P5, P6
1 2 3 4
+5 VDC (red)
common (black)
common (black)
+12 VDC (yellow)
P4
4 5 6
+3.3 VDC (orange)common (black)
321
+3.3 VDC (orange)common (black)
common (black) +3.3 VDC (orange)
P7
