A-2 Dell Dimension XPS R xxx Systems Service Manual
0DLQ6FUHHQ
)LJXUH $ 0DLQ 6FUHHQ 0HQX
7DEOH $ 0DLQ 6FUHHQ 0HQ X 2SWLRQV
2SWLRQ )XQFWLRQ
BIOS Version Displays the version of the BIOS being used.
Processor Type Displays the type of microprocessor installed.
Processor Speed Displays the internal speed of the microprocessor.
Cache RAM Indicates the amount of L2 cache memory installed.
Service Tag Displays the system’s service tag.
System Memory Displays the amount of system memory installed,
ranging from 32 to 384 MB, in the three DIMM sock-
ets on the system board.
Memory Bank
n Displays the size and type of memory in the DIMM
sockets.
Language Indicates the language in which the system setup
program is displayed.
ECC Configuration Appears on the screen only if the system detects an
all-ECC memory configuration. Leave this option set
to ECC (default) for optimum performance. To disable
ECC, select Non-ECC.
L2 Cache ECC
Support
When enabled (default), this option allows error check-
ing to occur on data accessed from the L2 cache. If
set to Disabled, error checking is not performed.
System Time Resets the time on the system’s internal clock.
System Date Resets the date on the system’s internal calendar.
