4-8 Dell Dimension XPS R xxx Systems Service Manual
8SSHU,QFK'ULYH
)LJXUH  8SSHU ,QFK 'ULYH 5HPRY DO
 5HPRYH WKH EH]HO
 5HPRYH WKH GULYH FDJH DQG GULYHV DV DQ DVVHPE O\
 5HPRYH WKH SODVWLF LQV HUW IURP WKH EH]HO
 5HPRYH WKH
 [  LQFK VFUHZ VHFXULQJ WKH GULYH EUDFNHW WR WKH
GULYH FDJH DQG WKHQ UHP RYH WKH EUDFNHW DV VKRZQ LQ )LJXUH 
NOTES: The three screws used to secure the drive to the bracket and to
the left side of the drive cage have 3-mm threads. Be sure to use the cor-
rect 3 x 5-mm screws when you secure the drive to the bracket and the
drive to the cage.
Also note which screw was used to secure the drive bracket to the drive
cage in step 4, and use the same
6/32
x
1/4
-inch screw when reinstalling the
bracket with its attached drive.
When you replace a drive, be sure to set the jumpers on the replacement drive
the same as the jumpers on the drive you removed. For additional information
about jumper settings on EIDE drives, see “EIDE Subsystem” in Chapter 1.
drive bracket
screws for
drive assembly (3)
drive-bracket
mounting screw
