NOTE: Shut down your system before you change the power sources.
12. Replace the dust caps on any unused ports.
13. When setting up the Edge Gateway for the first time, complete the operating system setup.
For more information, see Setting up your operating system.
NOTE:
MAC addresses and the IMEI number are available on the label at the front of the Edge Gateway. Remove the
label at install.
NOTE: The Edge Gateway is shipped with either Windows 10 IoT Enterprise LTSB 2016 or Ubuntu Core 16 operating
system.
NOTE: The default user name and password for Windows 10 IoT Enterprise LTSB 2016 is admin.
NOTE: The default user name and password for Ubuntu Core 16 is admin.
14. Access the BIOS by pressing F2 to enter the BIOS setup or F12 to enter the BIOS boot menu.
Windows 10 IOT Enterprise LTSB 2016
Click Start > All Programs > Dell > Command Configure > Dell Command | Configure Wizard.
Ubuntu Core 16
Use the dcc.cctk command to access the Dell Command | Configure application.
NOTE: For more information about BIOS settings on the Edge Gateway, see Default BIOS settings.
15. Install the Edge Gateway using one of the following mounting options:
NOTE: An open space of 63.50 mm (2.50 in) is recommended around the Edge Gateway for optimal air circulation.
● Standard mount
● DIN rail mount
● Quick mount
● Perpendicular mount
● Cable control bar
● VESA mount
Installing your Edge Gateway
19
