Mounting the Edge Gateway on a DIN rail using the DIN-rail bracket
NOTE: The DIN-rail bracket includes the screws that are required for securing the bracket to the Edge Gateway.
1. Align the screw holes on the DIN-rail bracket with the screw holes at back of the Edge Gateway.
2. Place the two M4x5 screws on the DIN-rail bracket and secure it to the Edge Gateway.
38
Installing your Edge Gateway
