10. Run the command to connect the to the Bluetooth keyboard.
$connect <MAC address of Bluetooth keyboard>
11. To quit the bluetoothctl console.
$quit
Switching between WLAN and Bluetooth modes
1. Unload the WLAN/BT driver.
$ modprobe -r ven_rsi_sdio
2. Adjust the mode in /etc/modprobe.d/rs9113.conf
3. Reload the WLAN/BT driver.
$ modprobe ven_rsi_sdio
4. Verify the operation mode. Refer to the table for operating mode values.
$ cat /sys/module/ven_rsi_sdio/parameters/dev_oper_mode
Table 9. Operating-mode values for WLAN and Bluetooth
Operating mode value Wi-Fi station BT/BLE modes
supported
softAP Clients supported by
softAP
1 X N/A N/A
1 N/A X 32
13 X Dual (BT classic and
BTLE)
N/A
14 Dual (BT classic and
BTLE)
X 4
5 X BT Classic N/A
6 BT Classic X 32
Bluetooth Serial Port Profile (SPP)
Assumptions for MAC addresses of each BT adapter:
● BT MAC(MYCLIENT): XX:XX:XX:XX:XX:XX
● BT MAC(MYSERVER): YY:YY:YY:YY:YY:YY
1. Pre-requirements (for Debian-only, not required on Ubuntu Core OS).
sudo apt-get install bluez bluez-tools
2. Prepare to pair MYSERVER and MYCLIENT
$ sudo bluez.bluetoothctl -a
[bluetoothctl]# power on
[bluetooth]# discoverable on
[bluetooth]# scan on
[NEW] Device XX:XX:XX:XX:XX:XX MYCLIENT
[bluetooth]# scan off
3. Pair with each other. As of Bluetooth v2.1, Secure Simple Pairing is a requirement, and offers three methods of pairing
devices, which are applicable on the Dell Gateway 3000 series:
● Just Works
● Numeric Comparison
Setting up the operating system
55
