Table 3. Left view (continued)
Features
NOTE: To comply with EU Declaration of Conformity (DoC), ensure cable
length from the system to the device does not exceed 30 meters.
NOTE: To comply with regulatory requirements in Brazil, ensure cable length
from the system to the device does not exceed 10 meters.
For information on how to configure Ethernet settings, such as duplex
configuration, see:
● Windows 10 IoT Enterprise LTSB 2016: Ethernet configuration
7 USB 3.0 port
1
Connect a USB enabled device. Provides data transfer speeds up to 5 Gbps.
8 SIM card slot (optional) Insert a micro-SIM card into the slot.
9 SD card slot (optional) Insert a micro-SD card into the slot.
NOTE: Remove the SD card slot filler before inserting a micro-SD card.
10 Quick Resource Locator label Scan with a QR reader to access documentation and other system information.
11 micro-SIM or micro-SD card
access door
Open the access door to access the micro-SIM or micro-SD card.
1
USB power is limited to 0.6 A/3 W.
Table 4. Status-light indicators
Function Indicator Color Control Status
System Power status and
System status
Green or Amber BIOS Off: System off
On (Solid Green):
System on or Boot
successful
On (Solid Amber):
Power up or boot fail
Blinking Amber: Fault or
error
WLAN or Bluetooth Green Hardware Off: WLAN or
Bluetooth module is off
On: WLAN or Bluetooth
module is on
Cloud Green Software Off: No connection to
the cloud device or
service
On: Edge Gateway
connected to a cloud
device or service
Blinking Green: Activity
to a cloud device or
service
LAN (RJ-45) Link Green/Amber Driver (LAN) Off: No network link or
cable is not connected
On (Green): High-
speed connection (100
Mbps)
8 System views
