Replacing the riser card
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Align the screws holes on the riser-card bracket with the screw holes on the riser
card.
2 Replace the screws that secure the riser-card bracket to the riser card.
3 Insert the riser card into the riser-card slots on the system board.
4 Align the screw holes on the riser-card with the screw holes on the chassis.
5 Replace the screws that secure the riser card to the chassis.
Post-requisites
1 Replace the PCI/PCIe card (if necessary).
2 Follow step 2 to step 8 in “Replacing the back cover”.
