Dell Embedded Box PC5000 Service Manual

Replacing the PCIe card
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Procedure
1 Install the PCI/PCIe cards in their respective slots on the riser board.
1 riser card 2 PCIe-card slot
3 PCIe card
47
