Removing the CANbus cable
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at www.dell.com/regulatory_compliance.
Prerequisites
1 Follow step 1 to step 6 in “Removing the back cover”.
2 Remove the PCI/PCIe card (if installed).
Procedure
1 Disconnect the CANbus cable from the connector on the CANbus card.
2 Remove the CANbus cable from the routing guides on the chassis.
3 Slide the cable out from under the heat sink pipe.
4 Remove the hexagonal screws that secure the CANbus port to the top cover.
