Replacing the drives in to the
hard-drive cage
WARNING: Before working inside your Embedded Box PC, read the safety
information that shipped with your Embedded Box PC and follow the steps
in Before working inside your Embedded Box PC. After working inside your
Embedded Box PC, follow the steps in After working inside your Embedded
Box PC. For more safety best practices, see the Regulatory Compliance
home page at
www.dell.com/regulatory_compliance.
CAUTION: Hard drives/solid-state drives are fragile. Exercise care when
handling the Solid-state/hard drive.
Procedure
NOTE: If the Embedded Box PC is shipped with two drives, the bottom drive
has to be replaced rst. For more information see, Procedure to replace
bottom drive.
1 Insert the drive into the hard-drive cage.
2 Align the screw holes on the drive with the screw holes on the hard-drive cage.
3 Replace the screws that secure the hard drive to the hard-drive cage.
Procedure to replace bottom drive
1 Insert the bottom drive into the bottom slot of the hard-drive cage and push it
down into place.
2 Align the screw holes on the bottom drive with the screw holes on the hard-drive
cage.
3 Replace the screws that secure the bottom drive to the hard-drive cage.
Post-requisites
Follow step 2 to step 8 in “Replacing the back cover”.
