Dell Embedded Box PC5000 Service Manual

Component Secured to Screw type Quantity
Top PCI plate M3x5 countersunk 1
VGA connector Top PCI plate D-sub HEX, #4–40UNCx6.3 2
CANbus cable Top PCI plate D-sub HEX, #4–40UNCx6.3 2
Top I/O plate Main chassis M3x5 countersunk 7
COM port cable Bottom I/O
plate
D-sub HEX, #4–40UNCx6.3 8
Bottom I/O plate Main chassis M3x5 countersunk 7
Rubber foot Back cover M3x8 4
Back cover Main chassis M3x5 countersunk 5
Hard-drive cage Back cover M3x5 4
Top hard drive/solid-
state drive
Hard-drive
cage
STDF(L5.1), M3x3 4
Bottom hard drive/
solid-state drive
Hard-drive
cage
STDF(L5.1), M3x3 4
Solid-state drive
interposer board
Solid-state
drive carrier
M2x3 3
Solid-state drive Solid-state
drive carrier
M2x3 2
Wall-mount bracket Back cover M3x8 4
14
