Dell EMC PowerEdge C6420 Installation And Service Manual

Figure 71. Removing system battery
Next steps
1. Install the system battery.
Installing the system battery
Prerequisites
WARNING:
There is a danger of a new battery exploding if it is incorrectly installed. Replace the battery only
with the same or equivalent type recommended by the manufacturer. For more information, see the safety
information that shipped with your system.
NOTE: Battery is a Field Replaceable Unit (FRU). Removal and installation procedures are to be performed only by Dell
certified service technicians.
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
Steps
1. Locate the battery socket. For more information, see the System board connectors section.
2. Hold the battery with the "+" facing up and slide it under the securing tabs.
3. Press the battery into the connector until it snaps into place.
Installing and removing enclosure components
77

Dell EMC PowerEdge C6420 Specifications

General

Processor	Intel Xeon Scalable processors
Management	iDRAC9
Max Processors	2 per node
Memory	DDR4
Storage	Up to 6 x 2.5" drives
Drive Bays	24 x 2.5" or 12 x 3.5"
Network	2 x 10GbE ports per sled
Power Supply	Dual, 2000W
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Maximum RAM	Up to 3TB per node
Max Memory	Up to 3TB per node
