Dell EMC PowerEdge C6420 Installation And Service Manual

Mezzanine and OCP cards
Removing a mezzanine card
Prerequisites
NOTE: The procedure to remove the mezzanine blank is similar to the removal of a mezzanine card.
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the expansion card riser assembly.
Steps
1. Remove the screws that secure the mezzanine card to the sled.
2. Lift the mezzanine card out of the sled.
NOTE: Install an expansion card filler bracket over an empty expansion slot to maintain Federal Communications
Commission (FCC) certification of the system. The brackets also keep dust and dirt out of the system and aid in proper
cooling and airflow inside the system.
Installing and removing enclosure components 71

Dell EMC PowerEdge C6420 Specifications

General

Processor	Intel Xeon Scalable processors
Management	iDRAC9
Max Processors	2 per node
Memory	DDR4
Storage	Up to 6 x 2.5" drives
Drive Bays	24 x 2.5" or 12 x 3.5"
Network	2 x 10GbE ports per sled
Power Supply	Dual, 2000W
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Maximum RAM	Up to 3TB per node
Max Memory	Up to 3TB per node
