Dell EMC PowerEdge R740 - Chassis Weight

Figure 16. System dimensions of PowerEdge R740 system
Table 15. Dimensions
System Xa Xb Y Za (with
bezel)
Za (without
bezel)
Zb Zc
PowerEdge R740 482.0 mm
(18.98
inches)
434.0 mm
(17.09 inches)
86.8 mm
(3.42 inches)
35.84 mm
(1.41 inches)
22.0 mm
(0.87 inches)
678.8 mm
(26.72
inches)
715.5 mm
(28.17 inches)
Chassis weight
Table 16. Chassis weight
System Maximum weight (with all hard drives/SSDs)
2.5 inch hard drive systems 26.3 kg (57.98 lb)
3.5 inch hard drive systems 28.6 kg (63.05 lb)
