Conguration Description Memory population rules
NVDIMM-N – C1{7},C2{7}
Conguration 3 23x 32 GB RDIMMs, 1x NVDIMM-N
RDIMMs – C1{1,2,3,4,5,6,7,8,9,10,11,12},
C2{1,2,3,4,5,6,7,8,9,10,11}
NVDIMM-N – C2{12}
Conguration 4 12x 16 GB RDIMMs, 2x NVDIMM-Ns
RDIMMs – Same for all 12x RDIMM
congurations. See Cong 1
NVDIMM-N – C1{7}, C2{7}
Conguration 5 12x 32 GB RDIMMs, 2x NVDIMM-Ns
RDIMMs – Same for all 12x RDIMM
congurations. See Cong 1
NVDIMM-N – C1{7}, C2{7}
Conguration 6 22x 32 GB RDIMMs, 2x NVDIMM-Ns
RDIMMs – C1{1,2,3,4,5,6,7,8,9,10,11},
C2{1,2,3,4,5,6,7,8,9,10,11}
NVDIMM-N – C1{12}, C2{12}
Conguration 7 12x 16 GB RDIMMs, 4x NVDIMM-Ns
RDIMMs – Same for all 12x RDIMM
congurations. See Cong 1
NVDIMM-N – C1{7,8}, C2{7,8}
Conguration 8 22x 32 GB RDIMMs, 4x NVDIMM-Ns
RDIMMs – Same for all 12x RDIMM
congurations. See Cong 1
NVDIMM-N – C1{7,8}, C2{7,8}
Conguration 9 20x 32 GB RDIMMs, 4x NVDIMM-Ns
RDIMMs – C1{1,2,3,4,5,6,7,8,9,10},
C2{1,2,3,4,5,6,7,8,9,10}
NVDIMM-N – C1{11,12}, C2{11,12}
Conguration 10 12x 16 GB RDIMMs, 6x NVDIMM-Ns
RDIMMs – Same for all 12x RDIMM
congurations. See Cong 1
NVDIMM-N – C1{7,8,9}, C2{7,8,9}
Conguration 11 12x 32 GB RDIMMs, 6x NVDIMM-Ns
RDIMMs – Same for all 12x RDIMM
congurations. See Cong 1
NVDIMM-N – C1{7,8,9}, C2{7,8,9}
Conguration 12 18x 32 GB RDIMMs, 6x NVDIMM-Ns
RDIMMs – C1{1,2,3,4,5,6,7,8,9},
C2{1,2,3,4,5,6,7,8,9}
NVDIMM-N – C1{10,11,12}, C2{10,11,12}
Conguration 13 12x 16 GB RDIMMs, 12x NVDIMM-Ns
RDIMMs – Same for all 12x RDIMM
congurations. See Cong 1
NVDIMM-N – C1{7,8,9,10,11,12},
C2{7,8,9,10,11,12}
