Chassis Management Controller Module
external management network. STK port allows CMCs in
adjacent enclosures to be daisy chained.
Serial 9-pin, DTE, 16550-compatible
Video 15-pin VGA
Battery CR 2032 3.0-V Lithium ion coin cell
Enclosure Control Panel
Externally accessible connectors
USB Two 4-pin, USB 2.0-compliant connectors for keyboard and
mouse support
Video 15-pin VGA
LCD panel features Four cursor control keys, one select key, LCD screen
I/O Module Specifications
Cisco Nexus B22 Fabric Extender Module
Externally accessible connectors Sixteen 10 Gb (internal) Ethernet ports and Eight 10 Gigabit
Ethernet SFP+ ports that support 10Gbase-SR, 10Gbase-LR,
and 10Gbase-ER fabric connections.
Brocade M6505 16 Gbps FC SAN I/O Module
Externally accessible connectors Eight physical FC8 ports that support 4/8/16 Gbps fibre
channel connections
Serial Port RJ-45
Dell PowerEdge M I/O Aggregator Switch Module
Externally accessible connectors
Serial 4-pin, USB 2.0 type A connector. Must use provided USB
type A to DB9 adapter to connect to terminal.
Optional Modules Two fixed 40 GbE ports that operate in 4x10 GbE mode.
Dell Force10 MXL 10/40 GbE Switch Module
Externally accessible connectors
Serial 4-pin, USB 2.0 type A connector. Must use provided USB
type A to DB9 adapter to connect to terminal.
Optional Modules Two optional bays. Each bay supports an Uplink module
with four 40 GbE optical SFP+ connectors, or 10GBASE-T
module using RJ-45 connectors.
