Alarms | 75
C
Alarms
The E1200 generates major and minor alarms for the following conditions:
• fan trays status
• Power Supply status
• fan tray status
• power supply status
• RPMs status
• high temperature on RPMs
• line cards status
• high temperature on line cards
• SFMs status
• high temperature on SFMs.
A major alarm is any fault that would render the E1200 non-functional.
A minor alarm is any fault that threatens the operation of the E1200.
You can monitor alarm conditions on the E1200 system through the console, LEDs, and audible alarms. If
you configure the SNMP command (snmp-server enable traps envmon), the FTOS also sends an
SNMP trap.
In the E1200 system, alarms are logged for each occurrence, but the system may not send an event log for
multiple occurrences. For example, whenever a module exceeds the shutdown threshold, the module
shuts down. If more than one module exceeds the warning or high temperature thresholds within a five
minute period, the system generates one event for all effected modules, but alarms are logged for each
occurrence. If the modules temperature falls to 5° lower than the warning threshold temperature, the
system clears the alarm and an SNMP trap.
Table C-1. Alarm Events and Reporting
Module Alarm Event Alarm LED Reported in
event log
Status LED on
Module
Audible
Alarm?
Fans Entire Fan Tray fails major (red) major unlit yes
1 or 2 individual fans fail minor (amber) minor unlit no
Power
Supply
Power Supply input power fail major (red) major unlit yes
Power Supply power fails at boot
a
unlit not reported unlit no
