Dell Latitude 3490 User Manual

Option Description
○ Legacy External Devices
○ UEFI (System Default)
Advanced Boot
Options
This option allows you the legacy option ROMs to load. By default, the Enable Legacy Option ROMs is
disabled. Enable Attempt Legacy Boot is enabled by default.
UEFI boot path
security
● Always, except internal HDD ( Default)
● Always
● Never
Date/Time Allows you to change the date and time.
System Configuration screen options
Option
Description
Integrated NIC Controls the on-board LAN controller. The option Enable Network Stack is not selected by default.
options:
● Disabled
● Enabled
● Enabled w/PXE (default)
SATA Operation Allows you to configure the operating mode of the integrated SATA hard drive controller.
● Disabled
● AHCI
● RAID On — default
Drives Allows you to enable or disable various drives on board.
● SATA-0 (default)
● SATA-2 (default)
● M.2 PCIe SSD-0 (default)
SMART
Reporting
Controls whether hard drive errors for integrated drivers are reported during system startup. The option
‘Enable Smart Reporting’ is not selected by default.
USB
Configuration
This is an optional feature.
This field configures the integrated USB controller. If Boot Support is enabled, the system is allowed to
boot any type of USB Mass Storage Devices—HDD, memory key, floppy.
If USB port is enabled, device attached to this port is enabled and available for OS.
If USB port is disabled, the OS cannot see any device attached to this port.
The options are:
● Enable USB Boot Support (default)
● Enable External USB Port (default)
NOTE: USB keyboard and mouse always work in the BIOS setup irrespective of these settings.
Dell Type-C Dock
Configuration
The option ‘Always Allow Dell Docks’ is selected by default.
When set to enabled, allows connection to the Dell WD and TB family of docks (Type-C docks)
independent of USB and Thunderbolt Adapter configuration settings.
When set to disabled, the docks will be controlled via the USB and Thunderbolt Adapter configuration
settings.
USB PowerShare This field configures the USB PowerShare feature behavior. This option allows you to charge external
devices using the stored system battery power through the USB PowerShare port. The option Enable
USB Powershare is disabled by default.
Audio This field enables or disables the integrated audio controller. By default, the Enable Audio option is
selected. The options are:
System setup options 79

Dell Latitude 3490 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Market positioning	Business
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 8 GB
AC adapter included	Yes
HDD size	2.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	No
Total storage capacity	500 GB
Compatible memory cards	SD, SDHC, SDXC
Number of HDDs installed	1
On-board graphics card ID	0x5917
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 620
On-board graphics card family	Intel® UHD Graphics
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1100 MHz
Audio chip	Realtek ALC3246
Audio system	MaxxAudio Pro
Speaker power	2 W
Speakers manufacturer	Waves
Number of built-in speakers	2
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
Front camera signal format	720p
Front camera resolution (numeric)	0.92 MP
Antenna type	2x2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Qualcomm QCA61x4A
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
DisplayPorts quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing device	Touchpad
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.34 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 10668 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Pixel pitch	0.226 x 0.226 mm
Pixel density	112 ppi
Display surface	Matt
Display diagonal	14 \
Display brightness	220 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	300:1
Bus type	OPI
Stepping	Y0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	8
Processor codename	Kaby Lake R
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	1.8 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Operating system language	ENG, ESP, FRE
Battery capacity	56 Wh
Processor code	SR3LA
Processor ARK ID	124967
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	241.9 mm
Width	339 mm
Height	21 mm
Weight	1780 g
