Dell Latitude E6440 - Removing the Processor; Installing the Processor; Removing the Power Connector

5. Follow the procedures in After Working Inside Your Computer .
Removing the Processor
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a. battery
b. base cover
c. heatsink assembly
3. Rotate the processor-cam lock in a counter-clockwise direction. Remove the processor from the computer.
Installing the Processor
1. Align the notches on the processor and the socket, and insert the processor into the socket.
2. Rotate the processor-cam lock in a clockwise direction.
3. Install:
a. heatsink assembly
b. base cover
c. battery
4. Follow the procedures in After Working Inside Your Computer .
Removing the Power Connector
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
a. battery
b. base corner cap (right)
c. base cover
