Installing the M.2 PCIe SSD
1. Insert the M.2 PCIe SSD to the connector.
2. Press the blue tab to secure the M.2 PCIe SSD.
3. Install the:
a. Optical drive
b. 2.5–inch drive assembly
c. bezel
d. cover
4. Follow the procedure in After working inside your computer.
Heat sink
Removing heat sink assembly
NOTE: Depending on the configuration you order, you may see either of the heat sinks as shown in the image below.
22 Disassembly and reassembly
