Table 3. Temperature, Shock, Vibration (continued)
Temperature M.2 2280 form factor
Non-operating 30º C/hr (Typical)
Humidity
Operating
Non-operating
5–95%
5–95%
Shock and Vibration Range
Shock
4
Operating
Non-operating
1500 G / 0.5 ms
230 G / 3 msec
Vibration
5
Operating
Non-operating
2.17 G
RMS
(5–800Hz) Max
3.13 G
RMS
(5–800Hz) Max
NOTES:
1. Operating temperature is targeted for 70º C.
2. Please contact your Intel representative for details on the non-operating temperature range.
3. Temperature gradient measured without condensation.
4. Shock specification assume the device is mounted securely with the input vibration applied to the drive-mounting screws.
Stimulus may be applied in the X,Y, or Z axis and shock specification is measured using Root Mean Squared (RMS) value.
5. Vibration specifications assume the device is mounted securely with the input vibration applied to the drive-mounting
screws. Stimulus may be applied in the X, Y, or Z axis. Vibration specificities is measured using RMS value.
Troubleshooting
1. The Intel Optane Memory model name "NVME INTEL MEMPEK1W01" in Device Manager does not match in the Intel Rapid
Storage Technology user interface; it only shows a part of the serial number information. This is a known issue and does not
impede the functionality of the Intel Optane Memory.
Device Manager: NVME INTEL MEMPEK1W01
IRST UI: INTEL MEMPEK1W016GA
2. During the first-time boot up, the system will scan the pairing status as below screen shot after shutdown. It’s working as
designed and the message will not appear again in following boot ups.
44
M.2 Intel Optane Memory Module 16 GB
