Dell OptiPlex 7050 Small Form Factor - Page 35

5. Disconnect the following cables and screw from the system board:
a. PSU [1]
b. hard drive and optical drive caddy stand off screw [2]
c. PSU [3]
d. power switch [4]
e. intrusion switch [5]
Disassembly and reassembly
35
