3. Align the tabs on the front I/O-bracket with the slots on the chassis.
4. Replace the two screws (#6-32) to secure the front I/O-bracket to the chassis.
Next steps
1. Install the front bezel.
2. Install the side cover.
3. Follow the procedure in After working inside your computer.
Wireless antenna kit
Internal antenna module
Removing the internal antenna module
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the wireless card.
About this task
The following images indicate the location of the internal antenna module and provide a visual representation of the removal
procedure.
Removing and installing Field Replaceable Units (FRUs)
77
