Configuring System Information 109
Viewing System Health Information
The System Health page physical device hardware information. To open the System Health
page:
•Click System > General > Health in the Tree View. The System Health page opens.
System Health Page
The System Health page contains the following fields:
• Unit—Indicates the stacking unit number.
• Main Power Supply Status—Indicates the main power supply state. The possible field
values are:
– —Indicates the main power supply is operating normally for the specified unit.
– —Indicates the main power supply is not operating normally for the specified
unit.
– Not Present—Indicates that the power supply is not present for the specified unit.
• Redundant Power Supply Status—Indicates the redundant power supply state. The
possible field values are:
– —Indicates the redundant power supply is operating normally for the specified
unit
