538 Dell PowerConnect 55xx Systems User Guide
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Maintenance Projects\Dell
Contax\CxUGSwitching_Multicast.fm
DELL CONFIDENTIAL – PRELIMINARY 9/11/12 - FOR PROOF ONLY
The following is an example of the CLI commands:
Multicast TV VLAN Mapping
To set the Multicast Group IP address for a TV VLAN:
1
Click Switching > Multicast Support > Multicast TV VLAN Mapping
in the tree view to display the Multicast TV VLAN Mapping: Summary
page.
Figure 16-7. Multicast TV VLAN Mapping: Summary
The Multicast Group IP addresses for the selected TV VLAN are displayed.
2 To add the Multicast Group IP address for a VLAN, click Add , and enter
the fields:
•
VLAN ID — Enter a VLAN ID.
console # show vlan multicast-tv vlan 1
Source Ports
-------------------------------------
gi1/0/8, gi1/0/9
Receiver Ports
-------------------------------------
gi2/0/1-18, gi3/0/1-18, gi4/0/1-18
