654 Dell PowerConnect 55xx Systems User Guide
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Maintenance Projects\Dell
Contax\CxUGQoS.fm
DELL CONFIDENTIAL – PRELIMINARY 9/11/12 - FOR PROOF ONLY
General
This section contains the following topics:
•QoS Mode
•QoS Properties
• Queue
• Mapping to Queue
•Bandwidth
• TCP Congestion Avoidance
QoS Mode
To enable/disable the QoS mode:
1
Click
Quality of Service
>
General
>
QoS Mode
in the tree view to
display the
QoS Mode
page.
Figure 22-1. QoS Mode
2
Select the
QoS Mode
. The possible options are:
–
Basic
— QoS is enabled in Basic mode on the switch
