Dell Precision M4600 - LVDS and Camera Cable Procedures; Removing LVDS Camera Cable

Low-Voltage Differential Signaling
(LVDS) Camera Cable 35
Removing The Low-Voltage Differential Signaling (LVDS) Camera Cable
1. Follow the procedures in
Before Working On Your Computer .
2. Remove the
battery .
3. Remove the
base cover .
4. Remove the keyboard trim .
5. Remove the
keyboard .
6. Remove the optical drive .
7. Remove the hard drive .
8. Remove the
palm rest .
9. Remove the display assembly .
10. Remove the standard display bezel or the touchscreen display bezel .
11. Remove the standard display panel or the touchscreen display panel .
12. Remove the display hinge, hinge cap, hinge tower .
13. Disconnect the low-voltage differential signaling (LVDS) and camera cable
from the camera.
14. Pry up the LVDS and camera cable from the display cover.
111
