Installing The CPU Heatsink
1. Locate the heatsink compartment on the system.
2. Tighten the captive screws (1 > 2 > 3). Ensure the heatsink is properly
aligned and seated over the processor.
3. Install the
palm rest
.
4. Install the
CPU fan
.
5. Install the
hard drive
.
6. Install the
optical disc drive.
7. Install the
keyboard
.
8. Install the
keyboard trim
.
9. Install the
base cover
.
10. Install the
battery
.
11. Follow the procedures in
After Working Inside Your Computer
.
58
