Contactless Smart Card
ISO15693
HID iClass
FIPS201
NXP Desfire
Physical M4600 M6600
Height 36.5 mm (1.44 inches) 37.20 mm (1.46 inches)
Width 376 mm (14.80 inches) 416.70 mm (16.41 inches)
Depth 256 mm (10.08 inches) 270.60 mm (10.65 inches)
Weight (Minimum) 2.77 kg (6.11 lb with 6-cell
and airbay)
3.52 kg (7.77 lb with 9-cell
and airbay)
Environmental
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity (maximum):
Operating 10 % to 90 % (non-condensing)
Storage 5 % to 95 % (non-condensing)
Maximum vibration:
Operating 0.66 GRMS
Storage 1.3 GRMS
Maximum shock:
Operating 140 G
Storage 163 G
Altitude:
Operating –15.2 m to 3048 m (–50 ft to 10,000 ft)
Storage –15.2 m to 10668 m (–50 ft to 35,000 ft)
121
