Dell Remote Access Controller 4 Firmware Version 1.30 - DRAC 4 Hardware Features

22 DRAC 4 Overview
www.dell.com | support.dell.com
DRAC 4 Hardware Features
Figure 1-1 shows the DRAC 4/I hardware and Figure 1-2 shows the DRAC 4/P hardware.
Figure 1-1. DRAC 4/I Hardware Features
Figure 1-2. DRAC 4/P Hardware Features
RJ-45 Connector
RJ-45 Connector
Video Connector
Management Connector
