DRAC 4 Property Database Group and Object Definitions 221
where <bmcMask> has the following bit definitions:
• Bit-0: 1 = Send alert for DRAC 4 communication with BMC and lost or restored
communication between the DRAC 4 and BMC.
• Bit-1: 1 = Send alert for DRAC 4 lost communication with BMC.
• Bit-2: Reserved.
• Bit-3: Reserved.
Examples
• If you want to define alerts for the following:
– Critical voltage or temperature sensors
– Lost communication with the BMC
then the event mask property value to use is
0x02244444 . The following command sets this
property value:
racadm -g cfgUserAdmin -o cfgUserAdminAlertFilterRacEventMask
-i1 0x2244444
• If you want to define alerts for the following:
– Critical events
– System power off
– Watchdog timer hang
then the event mask property value to use is
0x00064444 . The following command sets this
property value:
racadm -g cfgTraps -o cfgTrapsFilterSysEventMask -i1 0x00064444
System-Generated Alert Mask Definitions
The cfgTraps cfgTrapsFilter {Rac, Sys} EventMask properties are an unsigned 32-bit integer
property that holds the filter information for managed-system generated events. The bit
definitions in
Ta b le B-4 apply.
Table B-3. DRAC 4-Generated Event Mask Bit Definitions
Bits Data Type
28–31 DRAC 4 undefined reserved
24–27 DRAC 4 miscellaneous alerts <Miscmask>
20–23 DRAC 4 BMC communication alerts <BMCmask>
