Using the DRAC 4 With Microsoft
®
Active Directory 91
4 Click Next to run the Dell Schema Extender.
5 Click Finish .
The schema is extended. To verify the schema extension, use the Microsoft Management
Console (MMC), the Active Directory Schema snap-in to verify the existence of the following
classes (listed in Table 5-1, Table 5-2, Table 5-3, Table 5-4, Table 5-5, and Table 5-6) and
attributes (listed in Table 5-7). See your Microsoft documentation for more information on
how to enable and use the Active Directory Schema snap-in the MMC.
Table 5-1. Class Definitions for Classes Added to the Active Directory Schema
Class Name Assigned Object Identification Number (OID)
dellRacDevice
1.2.840.113556.1.8000.1280.1.1.1.1
dellAssociationObject 1.2.840.113556.1.8000.1280.1.1.1.2
dellRAC4Privileges 1.2.840.113556.1.8000.1280.1.1.1.3
dellPrivileges 1.2.840.113556.1.8000.1280.1.1.1.4
dellProduct 1.2.840.113556.1.8000.1280.1.1.1.5
Table 5-2. dellRacDevice Class
OID 1.2.840.113556.1.8000.1280.1.1.1.1
Description
This class represents the Dell RAC device. The RAC device must be
configured as dellRacDevice in Active Directory. This configuration enables
the DRAC 4 to send Lightweight Directory Access Protocol (LDAP) queries
to Active Directory.
Class Type Structural Class
SuperClasses dellProduct
Attributes dellSchemaVersion
dellRacType
Table 5-3. dellAssociationObject Class
OID 1.2.840.113556.1.8000.1280.1.1.1.2
Description
This class represents the Dell Association Object. The Association Object
provides the connection between the users and the devices.
Class Type Structural Class
SuperClasses Group
Attributes dellProductMembers
dellPrivilegeMember
