Dell S2830dn User Manual

3 Remove the imaging unit.
Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes.
Extended exposure to light may cause print quality problems.
Warning—Potential Damage: Do not touch the shiny photoconductor drum under the imaging unit.
Doing so may aect the quality of future print jobs.
4 Remove the jammed paper.
Note: Make sure that all paper fragments are removed.
5 Insert the imaging unit.
Note: Use the arrows inside the printer as guides.
Clearing jams 101

Dell S2830dn Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Memory	512 MB
Processor Speed	800 MHz
Printer Type	Monochrome Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Standard Connectivity	USB 2.0
Maximum Paper Size	A4
Paper Input Capacity	250-sheet standard input tray, 50-sheet multipurpose tray
