Dell S2830dn User Manual

Warning—Potential Damage: Do not touch the USB cable, any network adapter, or the printer in the area
shown while actively printing. Loss of data or a malfunction can occur.
Use the To
1 USB port Attach an optional wireless network adapter.
2 USB printer port Connect the printer to a computer.
3 Ethernet port Connect the printer to a network.
4 Parallel port Connect the printer to a computer.
5 Power switch Turn on or turn o the printer.
6 Printer power cord socket Connect the printer to an electrical outlet.
7 Security slot Attach a lock that will secure the printer in place.
Setting up the printer software
Installing the printer
1 Obtain a copy of the software installer package.
2 Run the installer, and then follow the instructions on the computer screen.
3 For Macintosh users, add the printer.
Note: Obtain the printer IP address from the TCP/IP section in the Network/Ports menu.
Additional printer setup 18

Dell S2830dn Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Memory	512 MB
Processor Speed	800 MHz
Printer Type	Monochrome Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Standard Connectivity	USB 2.0
Maximum Paper Size	A4
Paper Input Capacity	250-sheet standard input tray, 50-sheet multipurpose tray
