Installing display hinge
1 Place the display hinge cover on the display assembly.
2 Replace the screws to secure the display hinge cover to the display assembly.
3 Install the:
a display panel
b display bezel
c display assembly
d WLAN card
e base cover
4 Follow the procedure in After working inside your computer.
DC-in
Removing the DC-in
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b WLAN card
c display assembly
3 To remove the DC-in:
a Remove the 3 M2.5 x 6 screws that secure the right display hinge bracket to the system [1].
b Lift the hinge bracket [2].
c Disconnect the power-adapter port cable from the connector in the system board [3].
Removing and installing components
33
