Delta Electronics AC Servo Drive ASDA-AB User Manual

Chapter 3 Connections and Wiring|ASDA-AB Series
Revision January 2009 3-21
DI
Signal
DI
Code
Assigned
Control
Mode
Pin No.
(Default)
Details
(*2)
Wiring Diagram
(Refer to 3-3-3)
JOGU 37
Not
assigned
-
Forward JOG input. When JOGU is
activated, the motor will JOG in forward
direction. [see P4-05]
JOGD 38
Not
assigned
-
Reverse JOG input. When JOGD is
activated, the motor will JOG in reverse
direction. [see P4-05]
STEPU 39
Not
assigned
-
Step up input. When STEPU is activated,
the motor will run to next position.
STEPD 40
Not
assigned
-
Step down input. When STEPD is
activated, the motor will run to previous
position.
STEPB 41
Not
assigned
-
Step back input. When STEPB is
activated, the motor will return to first
position.
AUTOR 42
Not
assigned
-
Auto run input. When AUTOR is activated,
the motor will run automatically according
to internal position command. For time
interval setting, please see P2-52 to P2-
59.
GNUM0 43
Not
assigned
-
Electronic gear ratio (Numerator) selection
0 [See P2-60~P2-62]
GNUM1 44
Not
assigned
-
Electronic gear ratio (Numerator) selection
1 [See P2-60~P2-62]
INHP 45
Not
assigned
-
Pulse inhibit input. When the drive is in
position mode, if INHP is activated, the
external pulse input command is not valid.
C9/C10
Footnote *2: The "state" of the input function may be turned ON or OFF as it will be dependant on the
settings of P2-10~P2-17.
