Delta AH Series Hardware Manual

Chapter 2 System Configuration
2-7
2
_
Component Model Name Description
AH64AN02P-5C
12~24 VDC
0.1 A
64 outputs
Sourcing output
MIL connector
AH16AN01S-5A
100~240 VAC
0.5 A
16 outputs
TRIAC
Terminal block
Analog
input/output
module
AH04AD-5A
Four-channel analog input module
Hardware resolution: 16 bits
0/1 V~5 V, -5 V~5 V, 0 V~10 V, -10 V~10 V, 0/4 mA~20 mA, and -20
mA~20 mA
Conversion time: 150 us/channel
AH08AD-5A
Eight-channel analog input module
Hardware resolution: 16 bits
0/1 V~5 V, -5 V~5 V, 0 V~10 V, -10 V~10 V, 0/4 mA~20 mA, and -20
mA~20 mA
Conversion time: 150 us/channel
AH08AD-5B
Eight-channel analog input module
Hardware resolution: 16 bits
0/1 V~5 V, -5 V~5 V, 0 V~10 V, and -10 V~10 V
Conversion time: 150 us/channel
AH08AD-5C
Eight-channel analog input module
Hardware resolution: 16 bits
0/4 mA~20 mA, and -20 mA~20 mA
Conversion time: 150 us/channel
AH04DA-5A
Four-channel analog output module
Hardware resolution: 16 bits
0/1 V~5 V, -5 V~5 V, 0 V~10 V, -10 V~10 V, and 0/4 mA~20 mA
Conversion time: 150 us/channel
AH08DA-5A
Eight -channel analog output module
Hardware resolution: 16 bits
0/1 V~5 V, -5 V~5 V, 0 V~10 V, -10 V~10 V, and 0/4 mA~20 mA
Conversion time: 150 us/channel
AH08DA-5B
Eight-channel analog output module
Hardware resolution: 16 bits
0/1 V~5 V, -5 V~5 V, 0 V~10 V, and -10 V~10 V
Conversion time: 150 us/channel
AH08DA-5C
Eight-channel analog output module
Hardware resolution: 16 bits
0/4 mA~20 mA
Conversion time: 150 us/channel
AH06XA-5A
Four-channel analog input module
Hardware resolution: 16 bits
0/1 V~5 V, -5 V~5 V, 0 V~10 V, -10 V~10 V, 0/4 mA~20 mA, and -20
mA~20 mA
