Chapter 2 Installation ASDA-M
2-14 Revision December, 2014
Dimensions of Regenerative Resistor
Delta Part Number: BR400W040 (400W 40Ω)
L1 L2 H D W MAX. WEIGHT (g)
265 250 30 5.3 60 930
Delta Part Number: BR1K0W020 (1kW 20Ω)
L1 L2 H D W MAX. WEIGHT (g)
400 385 50 5.3 100 2800
