Delta ASDA-M Series User Manual

Chapter 8 Parameters ASDA-M
8-310 Revision December, 2014
Setting Value: 0x3A
DO
Name
Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_A Ouput the status of bit 10 of P4-06 Level
triggered
ALL
Setting Value: 0x3B
DO
Name
Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_B Ouput the status of bit 11 of P4-06 Level
triggered
ALL
Setting Value: 0x3C
DO
Name
Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_C Ouput the status of bit 12 of P4-06 Level
triggered
ALL
Setting Value: 0x3D
DO
Name
Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_D Ouput the status of bit 13 of P4-06 Level
triggered
ALL
Setting Value: 0x3E
DO
Name
Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_E Ouput the status of bit 14 of P4-06 Level
triggered
ALL
Setting Value: 0x3F
DO
Name
Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_F Ouput the status of bit 15 of P4-06 Level
triggered
ALL
NOTE
1) When P2-18～P2-22 is set to 0, DO has no function.
