Delta ASDA-M Series User Manual

Appendix A Accessories ASDA-M
Revision December, 2014 A-19
2kW servo drive and 2kW medium-inertia motor
Servo Drive ASD-M-2023-
Medium-inertia Motor
ECMA-E△1820S
Motor Power Cable
(without brake)
ASD-CAPW200X
Motor Power Cable
(with brake)
ASD-CAPW210X
Power Connector ASD-CAPW2000
Incremental Type
Encoder Connector
ASD-CAEN100X
Absolute Type Encoder
Connector
ASD-A2EB100X
Encoder Connector ASD-CAEN1000
(X=3 indicates that the cable length is 3m; X=5 indicates that the cable length is 5m)
NOTE
1) Box, () at the end of the servo drive model names represents the product code of
ASDA-M. Please refer to the actual situation of purchasing.
2) Box, () in the model name of the servo motor represents brake or keyway / oil
seal.
3) Triangle, (ᇞ) represents the type of encoder. Please refer to Chapter 1 for detail
