Chapter 13 Warning CodesC2000 Plus
ID No. Display on LCD Keypad Warning Name Description
65
CAN/M SDO over
(PCSF)
CANopen Master SDO overflow
Action and Reset
Action condition
When the CANopen master transmits too much SDO that causes buffer overflow,
the PCSF warning displays
Action time Immediately displays when the fault is detected
Warning setting parameter N/A
Reset method Cycle the power, or stop the PLC and run the PLC again
Reset condition N/A
Record N/A
Cause Corrective Actions
Internal PLC transmits too much
SDO at once
The PLC program needs to confirm receiving the SDO
sending another SDO command.
