2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-73
M1017
±30 seconds
correction
From “Off” to “On”, the correction is enabled.
0 ~ 29 second: minute intact; second reset to 0
30~ 59 second: mimute + 1; second reset to 0
M1076 RTC malfunction Set value exceeds the range; dead battery
M1082 Flag change on RTC On: Modification on RTC
D1313 Second 0 ~ 59
D1314 Minute 0 ~ 59
D1315 Hour 0 ~ 23
D1316 Day 1 ~ 31
D1317 Month 1 ~ 12
D1318 Week 1 ~ 7
D1319 Year 0 ~ 99 (last 2 digits of Year in A.D.)
2. If the set value in RTC is incorrect, the time will be recovered as “Saturday, 00:00 Jan. 1, 2000” when PLC is
powered and restarted.
3. D1313 ~ D1319 will immediately update the RTC only when in TRD instruction or WPLSoft monitoring mode.
4. How to make corrections on RTC:
a) Use TWR instruction fir SA/SX/SX/EH/EH2/SV series MPU. See API 167 TWR for more details.
b) Use WPLSoft or digital display panel DU-01.
Function Group
π(PI)
Number
D1018, D1019
Contents:
1. D1018 and D1019 are combined as 32-bit data register for storing the floating point value ofπ
(PI)
2. loating point value = H 40490FDB
Function Group
Adjustment on Input Terminal Response Time
Number
D1020, D1021
Contents:
1. D1020 can be used for setting up the response time of receiving pulses at X0 ~X7 for SS/ES/EX/SA/SX/SC
series MPU. (Setup range: 0 ~ 20; Unit: ms)
2. D1021 can be used for setting up the response time of receiving pulses at X10 ~X17 for ES series MPU. (Setup
range: 0 ~ 20; Unit: ms)
3. D1021 can be used for setting up the response time of receiving pulses at X10 ~X11 for SC series MPU. (Setup
range: 0 ~ 1,000; Unit: time)
4. D1020 can be used for setting up the response time of receiving pulses at X0 ~X7 for EH/EH2/SV series MPU.
(Setup range: 0 ~ 60; Unit: ms)
