Delta DVP-PLC User Manual

5 Categories & Use of Application Instructions
DVP-PLC Application Manual
5-16
5.5 Instruction Index
Sorted by alphabetic order & API No.
Mnemonic Applicable to
Category
API
16-bit 32-bit
P
Instruction
Function
ES SA EH
Page
20
ADD DADD
3
Addition
3 3 3
6-32
46
ANS -
-
Timed Annunciator Set
-
3 3
6-66
47
ANR -
3
Annunciator Reset
-
3 3
6-66
62
ABSD DABSD
-
Absolute Drum Sequencer
-
3 3
7-46
66
ALT -
3
Alternate State
3 3 3
7-54
75
ARWS -
-
Arrow Switch
-
3 3
7-70
76
ASC -
-
ASCII Code Conversion
-
3 3
7-72
82
ASCI -
3
Converts Hex to ASCII
3 3 3
7-94
87
ABS DABS
3
Absolute Value
3 3 3
7-106
133
- DASIN
3
Arc Sine
-
3 3
8-49
134
- DACOS
3
Arc Cosine
-
3 3
8-50
135
- DATAN
3
Arc Tangent
-
3 3
8-51
155
- DABSR
-
Read the Absolute Position from a Servo Motor
-
3 3
9-14
172
- DADDR
3
Floating Point Addition
3 3 3
9-51
218
AND& DAND&
-
S
1
& S
2
-
3 3
10-8
219
AND| DAND|
-
S
1
| S
2
-
3 3
10-8
220
AND^ DAND^
-
S
1
^ S
2
-
3 3
10-8
232
AND= DAND=
-
S
1
= S
2
3 3 3
10-11
233
AND> DAND>
-
S
1
> S
2
3 3 3
10-11
234
AND< DAND<
-
S
1
< S
2
3 3 3
10-11
236
AND<> DAND<>
-
S
1
≠ S
2
3 3 3
10-11
237
AND<= DAND<=
-
S
1
≦ S
2
3 3 3
10-11
A
238
AND>= DAND>=
-
S
1
≧ S
2
3 3 3
10-11
15
BMOV -
3
Block Move
3 3 3
6-24
18
BCD DBCD
3
Binary Coded Decimal
3 3 3
6-29
19
BIN DBIN
3
Binary
3 3 3
6-30
B
44
BON DBON
3
Check Specified Bit Status
3 3 3
6-64
00
CJ -
3
Conditional Jump
3 3 3
6-1
01
CALL -
3
Call Subroutine
3 3 3
6-5
10
CMP DCMP
3
Compare
3 3 3
6-18
14
CML DCML
3
Compliment
3 3 3
6-23
84
CCD -
3
Check Code
-
3 3
7-101
108
CRC -
3
Checksum CRC Mode
-
3 3
8-19
131
- DCOS
3
Cosine
3 3 3
8-45
137
- DCOSH
3
Hyperbolic Cosine
- -
3
8-53
146
CVM -
-
Valve Control (*)
- -
3
8-63
193
- DCIMR
-
2-Axis Relative Position Arc Interpolation (*)
- -
3
9-81
194
- DCIMA
-
2-Axis Absolute Position Arc Interpolation (*)
- -
3
9-86
C
197
- DCLLM
-
Close Loop Position Control (*)
- -
3
9-95
05
DI -
-
Disable Interrupts
3 3 3
6-8
23
DIV DDIV
3
Division
3 3 3
6-37
25
DEC DDEC
3
Decrement
3 3 3
6-40
41
DECO -
3
Decode
3 3 3
6-59
72
DSW -
-
Digital Switch
-
3 3
7-64
117
- DDEG
3
Radian Æ Angle
-
3 3
8-27
D
143
DELAY -
9
Delay Instruction
-
9 9
8-55

Delta DVP-PLC Specifications

General

Manufacturer	Delta Electronics
Model	DVP-PLC
Category	Controller
Humidity	5% to 95% RH, non-condensing
Programming Language	Ladder Diagram (LD), Instruction List (IL), Sequential Function Chart (SFC)
CPU Type	Various, depending on the specific model within the DVP series (e.g., ES2, EX2, SX2, SA2, EH3, etc.)
Operating Temperature	Typically 0°C to 55°C (32°F to 131°F)
Storage Temperature	Typically -25°C to 70°C (-13°F to 158°F)
