9 Application Instructions API 150-199
DVP-PLC Application Manual
9-43
API Mnemonic Operands Function
166
TRD P
Time Read
Controllers
ES/EX/SS SA/SX/SC EH/SV
Bit Devices Word Devices Program Steps Type
OP
X Y M S K H KnX KnY KnM KnS T C D E F
D * * *
TRD, TRDP: 3 steps
PULSE 16-bit 32-bit
ES EX SS SA SX SC EH SV ES EX SS SA SX SC EH SV ES EX SS SA SX SC EH SV
Operands:
D: The device for storing the current time read in RTC
Explanations:
1. D will occupy 7 consecutive devices.
2. See the specifications of each model for their range of use.
3. Flags: M1016, M1017, M1076. See remarks for more details.
4. The built-in RTC in EH/EH2/SV/SA/SX/SC series MPU offers 7 data (year, week, month, day, hour, minute,
second) stored in D1319 ~ D1313. TRD instruction is for program designers to read the current data in RTC
and store the data to the 7 registers designated.
5. D1319 only reads the 2-digit year in A.D. If you wish D1319 to read the 4-digit year, see remarks for more
information.
Program Example:
1. When X0 = On, the instruction will read the current time in RTC to the designated registers D0 ~ D6.
2. The content of D1318: 1 = Monday; 2 = Tuesday … 7 = Sunday.
TRD
X0
Special D Item Content General D Item
D1319 Year (A.D.) 00~99
D0 Year (A.D.)
D1318
Day
(Mon ~ Sun)
1~7
D1
Day
(Mon ~ Sun)
D1317 Month 1~12
D2 Month
D1316 Day 1~31
D3 Date
D1315 Hour 0~23
D4 Hour
D1314 Minute 0~59
D5 Minute
D1313 Second 0~59
D6 Second
